- Introduction
Q26 Series Shot peening machine is special equipment designed to meet specific process requirements. Through the shot-peening can remov the complex work piece surface contamination, the oxide skin, welding slag, the waste paint and so on, causes the work piece surface to be bright and clean, simultaneously reduce the work piece internal stress, enabls the work piece surface to obtain the strengthening, thus achieves enhances the work piece surface and the intrinsic quality goal.
Technical parameters：
|
Name
|
Q2610
|
Q2615
|
Q2630
|
Q26100
|
Q26150
|
|
Workpiece weight（Kg）
|
10000
|
15000
|
30000
|
100000
|
150000
|
|
shot peening amount（Kg/h）
|
3600-4000
|
1800-2200
|
3600-4400
|
3600-4400
|
3600-4400
|
|
Working pressure（Mpa）
|
0.5-0.65
|
0.5-0.7
|
0.5-0.7
|
0.5-0.7
|
0.5-0.7
|
|
Elevating capacity（T/h）
|
15
|
15
|
15
|
30
|
60
|
|
Separating capacity(T/h)
|
15
|
15
|
15
|
30
|
60
|
|
Outline dimensions（mm）
|
6000*5500*4000
|
7128*4796*4168
|
20000*8000*8500
|
14000*8000*7500
|
27000*5800*6500
|
|
