Usage:
This machine is mainly used for crushing, screening, magnetic separation, the role of self-hardening sand sand block simultaneously the preliminary regeneration Tuomo function
Feature:
Built sturdy rotating cylinder swinging metal plate put into the sand block can be quickly crushed by mounted on the outside of the stainless steel metal mesh screening, the sand block burrs core iron, beans, and other not direct contact with the metal mesh can be used for a long. Casting burrs, core iron, iron beans in the opposite direction after the work rotating cylinder can be automatically excluded crushed the old sand is not greater than φ3mm sent to the next process from the lower part of the small belt conveyor belt nose wheel is permanent pulley, magnetic separation of the old sand, to ensure small iron beans will not flow into the next step. Native drum rotation by cycloid reducer driven chain drive, smooth running, low noise.
Model
|
Working efficiency (t/h)
|
Total power (KW)
|
Drum Dimension(mm)
|
Outline size(mm)
|
NSCP-5
|
5
|
4+1.1
|
φ970
|
3180x2655x2870
|
NSCP-10
|
10
|
5.5+2.2
|
φ1100
|
3525x2180x3525
|
Note:We can produced non-standard production following buyer's request.
|
