- Introduction
Purposes: In order to easy styling or regeneration, the old sand temperature adjusted to meet technical requirements.
Features: air flow through the boiling plate impulse to the hot sand, to make sand exchange heat in the boiling state with sand boiling board. Sand flow forward and suck the dust from sand stream.
|
Model
|
Productivity(T/h)
|
Temperature(℃)
|
Wind pressure(Pa)
|
Exhaust volume(m3/h)
|
The amount of cooling water(m3/h)
|
Note
|
|
FT10
|
10
|
≤32
|
＞0.1×105
|
＞6000
|
50
|
Water temperature higher than 20 ° C is recommended equipped with a water-cooled units.
|
|
FT15
|
15
|
≤32
|
＞0.1×105
|
＞7000
|
80
|
|
FT20
|
20
|
≤32
|
＞0.1×105
|
＞9000
|
100
|
|
FT25
|
25
|
≤32
|
＞0.1×105
|
＞11000
|
110
|
|
FT30
|
30
|
≤32
|
＞0.1×105
|
＞13000
|
150
|
|
Note: sand temperature according to the process need to be adjusted.
|
|
