DSZ41 Series Vertical parting flaskless shoot squeeze molding machine Parameter
|
Type
|
Sand model size(L×W×Upper box Height / lower box Height)mm
|
Molding speed (sand moold/hour)
|
Shooting pressure(MPa)
|
Surface compressive strength(MPa)
|
Outline dimensions(L×W×H)mm
|
|
DSZ416
|
600*480*（120～330）
|
300（discharge core time180～200）
|
0.25～0.3
|
1～1.2
|
5960*1300*3560
|
DSZ41 Series Vertical parting flaskless shoot squeeze molding machin applicable to small and medium-sized iron (gray cast iron, malleable cast iron, ductile cast iron) of mass production.It has many outstanding advantages such as high productivity, the dimensional precision and high surface quality, low noise, low labor intensity, simple lines, auxiliary equipment, small occupied area, process and low construction investment, energy saving and good working environment etc..
DSZ41 Series Vertical parting flaskless shoot squeeze molding machine technical characteristics
1. Adopt advanced design concept, so that the molding becomes a kind of high efficiency, easy work. With AMC series of clamp mould conveyer and belt cooling conveyer, can realize modeling automation.
2.Adopt the injection molding, high production efficiency, the compaction pressure stepless adjustable to 2MPa. Casting quality is good, hardness is greater than 80.
3. The hydraulic and pneumatic system using standard components, improve the level of universalization, the key parts are imported, improve the reliability of the machine.
4. The main oil cylinder adopts a combined oil cylinder structure, simplifies the structure of the complete machine.
5. Adopt a proportional valve control the hydraulic operation, stable and reliable work.
6. The hydraulic system has a closing force control function and a pressure sensor, ensure the main and auxiliary synchronization, avoid sand was crushed, and make full use of the template.
7. The moold precision is about 0.1 ～ 0.14mm.
8. The moold bottom plate, side plate, top plate cavity with high hardness wear resistance material, long service life.
9. The use of automatic control software, realize the production, testing, maintenance alarm, fault diagnosis and other functions of the automation and visualization. And can realize software upgrade synchronism with our company.
